Nicht metallische FRP-/KFRP-Rod Zentrale, die Pultruded-Technologie runde Form CSM Φ2.0 verstärkt
Produktdetails
kfrp Material
,FRP-Mitglied
Nicht-metallisches zentrales Stärke-Mitglied CSM, KFRP Rod Φ2.0 FRP/KFRP Rod
Wir sind nicht-metallischer zentrales Stärke-Mitgliedshersteller/-lieferant FRP Rod in China und bieten Stärkemitglied Pultruded FRP Rod für Faserlichtleiterkabel an.
Spezifikationen: (Rundes FRP: ∮0.4-∮5.0)
| Eigentum | Werte |
| Dehnfestigkeit (Mpa) | ≥1100 |
| Dehnbarer Modul (Gpa) | ≥50 |
| Biegefestigkeit (Mpa) | ≥1100 |
| Flexural Modul (Gpa) | ≥50 |
| Bruchdehnung (%) | ≤4 |
|
Koeffizient des linearem Thermal
Expansion (- 30-80℃) (1/℃) |
<8*10-6 |
| Durchmessertoleranz (Millimeter) | ±2% |
| Minimaler Biegungsradius (Millimeter) | 40*D |
| Dichte (g/cm3) | 2.05-2.15 |
| Biegeversuch der hohen Temperatur (50D, 100℃, 120h) |
Kein Büro, Sprung und
Bruch |
| Biegeversuch der niedrigen Temperatur (50D, - 40℃, 120h) |
Kein Büro, Sprung und
Bruch |
| Drehung (±360°/m) | Nicht aufgelöst |
We develop and produce Flat FRP strength member for different application.
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Cable Strengthen Core For Fiber Optical Cables Non-Metallic FRP Rod Central Strength Member CSM Basic Info Technique: Pultrusion Type: Themosetting Plastic Profiles Diameter Ranges: 0.40 mm to 5.00 mm HS Code: 70199090 Materials: Resin, E-glass Fiberglass, Agents, etc. Applications: Central or peripheral strength member for fiber optical cables Origin: Jiangsu, China Product Description: Non-metallic FRP Rod strength member, usually located at the center or the periphery of
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Unsere Mission ist es, "Hohe Qualität", "Guten Service" und "Schnelle Lieferung" anzubieten, um unseren Kunden zu helfen, mehr Gewinne zu erzielen.
